ASUS PRIME B840M-A WIFI Hovedkort AM5, micro-ATX, B840, DDR5, 1x PCIe 4.0, 3x M.2

Varenr.:
90MB1J20-M0EAY0
EAN:
4711387797143
  • Prosessorsokkel Socket AM5
  • Chipset AMD B840
  • M.2 Slot 3
  • Minnespor 4 x DIMM, DDR5
  • Maksimal RAM-frekvens 7.6GHz
  • Støttet maksimalt minne 256GB
  • Formfaktor Micro ATX
2 512,-
2 009,60 ekskl. mva
På lager i Oslo (Pickup point) Ikke på lager På hovedlager (1-3 arbeidsdager) Antall 17
Antall:
Legg i handlekurven

Fraktpriser

Venter...
Fyll inn postnummer og klikk knappen for å vise frakt priser
Vis priser
Beskrivelse
Spesifikasjoner

Prime B840M-A WIFI

ASUS Prime series motherboards are expertly engineered to unleash the full potential of AMD Ryzen™ 9000 series processors. The PRIME B840M-A WIFI motherboard provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. It’s designed to be Advanced AI PC-ready, offering the power and connectivity needed for demanding AI applications.

Specifications:

CPU
  • AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors
Chipset
  • AMD B840 Chipset
Memory
  • 4 x DIMM slots, max. 256GB, DDR5
  • Supports up to 7600+MT/s (OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors, ECC and Non-ECC, Un-buffered DIMM
  • Dual channel memory architecture
  • Supports AMD Extended Profiles for Overclocking (EXPO™)
  • ASUS Enhanced Memory Profile (AEMP)
Graphics
  • 2 x DisplayPort
  • 1 x HDMI™ port
Expansion Slots
  • AMD Ryzen™ 9000 & 7000 Series Desktop Processors 1 x PCIe 4.0 x16 slot (supports x16 mode)
  • AMD Ryzen™ 8000 Series Desktop Processors 1 x PCIe 4.0 x16 slot (supports x8/x4 mode)
  • AMD B840 Chipset 2 x PCIe 3.0 x16 slots (support x1 mode)
Storage
  • Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports
  • AMD Ryzen™ 9000 & 7000 Series Desktop Processors
    • M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
    • M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
  • AMD Ryzen™ 8000 Series Desktop Processors
    • M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
    • M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4/x2 mode)
  • AMD B840 Chipset
    • M.2_3 slot (Key M), type 2280 (supports PCIe 3.0 x4 mode)
    • 4 x SATA 6Gb/s ports
  • AMD RAIDXpert2 Technology
    • Ryzen™ 9000 Series Processors: RAID 0/1/5/10
    • Ryzen™ 8000 Series Processors: RAID 0/1
    • Ryzen™ 7000 Series Processors: RAID 0/1/10
Ethernet
  • 1 x Realtek 2.5Gb Ethernet
  • ASUS LANGuard
Wireless & Bluetooth
  • Wi-Fi 6E
  • 2x2 Wi-Fi 6E (802.11ax)
  • Supports 2.4/5/6GHz frequency band
  • Bluetooth® v5.3
USB
  • Rear USB (Total 7 ports)
    • 2 x USB 10Gbps ports (2 x Type-A)
    • 1 x USB 5Gbps port (1 x USB Type-C®)
    • 4 x USB 2.0 ports (4 x Type-A)
  • Front USB (Total 7 ports)
    • 1 x USB 5Gbps connector (supports USB Type-C®)
    • 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
    • 2 x USB 2.0 headers support 4 additional USB 2.0 ports
Audio
  • Realtek 7.1 Surround Sound High Definition Audio CODEC
    • Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
    • Supports up to 24-Bit/192 kHz playback
  • Audio Features
    • Audio Shielding
    • Premium audio capacitors
    • Dedicated audio PCB layers
Back Panel I/O Ports
  • 2 x USB 10Gbps ports (2 x Type-A)
  • 1 x USB 5Gbps port (1 x USB Type-C®)
  • 4 x USB 2.0 ports (4 x Type-A)
  • 2 x DisplayPort
  • 1 x HDMI™ port
  • 1 x Wi-Fi module
  • 1 x Realtek 2.5Gb Ethernet port
  • 3 x Audio jacks
  • 1 x BIOS FlashBack™ button
Internal I/O Connectors
  • Fan and Cooling Related
    • 1 x 4-pin CPU Fan header
    • 1 x 4-pin CPU OPT Fan header
    • 1 x 4-pin AIO Pump header
    • 3 x 4-pin Chassis Fan headers
  • Power Related
    • 1 x 24-pin Main Power connector
    • 1 x 8-pin +12V CPU Power connector
  • Storage Related
    • 3 x M.2 slots (Key M)
    • 4 x SATA 6Gb/s ports
  • USB
    • 1 x USB 5Gbps connector (supports USB Type-C® )
    • 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
    • 2 x USB 2.0 headers support 4 additional USB 2.0 ports
  • Miscellaneous
    • 3 x Addressable Gen 2 headers
    • 1 x Clear CMOS header
    • 1 x COM Port header
    • 1 x Front Panel Audio header (F_AUDIO)
    • 1 x S/PDIF Out header
    • 1 x SPI TPM header (14-1 pin)
    • 1 x 10-1 pin Front Panel System header
Special Features
  • ASUS 5X PROTECTION III
    • DIGI+ VRM
    • LANGuard
    • Overvoltage protection
    • SafeSlot Core+
    • Stainless-steel back I/O
  • ASUS Q-Design
    • Q-Antenna
    • Q-Dashboard
    • Q-DIMM
    • Q-LED Core
    • Q-Slot
  • ASUS Thermal Solution
    • M.2 heatsink
    • VRM heatsink design
  • ASUS EZ DIY
    • BIOS FlashBack™ button
    • BIOS FlashBack™ LED
    • Pre-mounted I/O shield
  • Aura Sync - Addressable Gen 2 headers
Software Features
  • ASUS Exclusive Software
  • Armoury Crate
    • Aura Creator
    • Aura Sync
    • Fan Xpert 2+
    • Power Saving
  • ASUS DriverHub
  • TurboV Core
  • ASUS CPU-Z
  • Norton 360 Deluxe (60 Days Free Trial)
  • WinRAR (40 Days Free Trial)
  • UEFI BIOS
  • ASUS EZ DIY
    • ASUS CrashFree BIOS 3
    • ASUS EZ Flash 3
    • ASUS UEFI BIOS EZ Mode
    • ASUS MyHotkey
BIOS
  • 256 Mb Flash ROM, UEFI AMI BIOS
Manageability
  • WOL by PME, PXE
Accessories
  • Cables 2 x SATA 6Gb/s cables
  • Miscellaneous
    • 1 x ASUS WiFi Q-Antenna
    • 1 x M.2 rubber package
    • 2 x Screw packages for M.2 SSD
  • Documentation 1 x Quick start guide
Operating System
  • Windows 11, Windows 10 64-bit
Form Factor
  • micro-ATX Form Factor
  • 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)
